The Amflow PL Carbon Pro (800Wh) XX-Large Cosmic Black is available at the following locations.
The item will be transferred to the location you choose during checkout.
If the item is not currently available to view at your desired location, please call your nearest store to arrange for it to be transferred.
Sale starts on 26th January 26 + limited stock remaining. This is a short-term offer and availability is changing quickly. To secure your bike, please call 01243 697547 or email sales@ebike-centre.co.uk to confirm current stock and lead times.
Now supplied with the Amflow integrated Avinox front light for a cleaner cockpit and improved visibility on trail-to-tarmac rides.
A 20.1kg full-suspension carbon e-MTB with an ultra-compact DJI Avinox drive system (up to 120Nm peak), an integrated 800Wh battery and a smart OLED display – built for riders who want real e-MTB power without carrying a 26kg bike.
Ultra-light, ultra-torquey and properly integrated – the Amflow PL Carbon Pro 2025 brings drone-grade DJI engineering to mountain biking, with enduro-ready travel and all-day range for UK and European riders (25 km/h / 15.5 mph compliant).
DJI Avinox drive – up to 120Nm peak
Frame-mounted OLED touchscreen
Ultra-light full-carbon chassis
Current stock is supplied with the Amflow / Avinox integrated front light for a clean setup and confident visibility on night rides, winter commutes and trail links.
The Amflow PL Carbon Pro runs an integrated 800Wh high-density battery (approx. 2.87kg) with battery-health management, intelligent discharge and safety alerts – built for genuine all-day e-MTB use.
Battery is fully integrated for stiffness and protection, but designed for long service life.
Both the PL Carbon Pro and PL Carbon share the same high-tech full-carbon chassis, the same DJI Avinox motor with up to 120Nm peak, and the same integrated 800Wh battery. The difference is in the component level: the Pro is for riders who want the very best suspension, brakes and drivetrain; the standard Carbon keeps the same performance DNA but uses a more accessible spec to hit a sharper price point.
In short: same platform, same power, two price points. Pick the Pro if you’ll actually use the top-end kit; pick the Carbon if you want the Avinox experience at the best value.
Frame: Full carbon, 2025 platform
Weight: approx. 20.1 kg
Battery: 800Wh integrated
Use: Enduro / big-mountain / hard trail
Motor: DJI Avinox, 105Nm continuous, up to 120Nm peak
Power: up to 850W peak
Display: Frame-mounted 2” OLED touchscreen
Assist limit: 25 km/h (15.5 mph)
The Amflow PL Carbon Pro 800Wh is part of a new wave of lightweight, full-power e-MTBs that don’t force riders to choose between range and agility. By using DJI’s Avinox drive unit – derived from extremely efficient drone technology – Amflow has achieved a rare mix of high peak torque (up to 120Nm), fast response, low noise and a very compact form factor. The result is a carbon e-MTB that still feels like a proper, modern enduro bike on technical UK singletrack, but has the battery capacity to ride all day.
For riders cross-shopping high-end enduro e-bikes from the usual big brands, this bike is an easy one to shortlist: it’s lighter than many Bosch/Yamaha/Shimano-powered full-fat e-MTBs, it has a bigger 800Wh battery than most “SL” style bikes, and it’s built around a full-carbon chassis. Paired with the Pro-level suspension and braking package, it’s aimed at riders who actually use the travel and power – coaches, guides, bike-park regulars, and e-MTB riders who want to keep up on long group rides.
Available at eBike-Centre with UK-spec 25 km/h (15.5 mph) assistance, supported by our workshop for setup, servicing and advice.
Learn more about the Amflow PL Carbon Pro 800Wh.
| Specification | Details |
|---|---|
| Frame | Amflow PL Carbon Frame – Cosmic Black / 150 mm rear travel / Compatible with 27.5" & 29" rear wheels |
| Motor System | DJI Avinox M1 Drive Unit (105 Nm) |
| Display | Avinox 2-inch OLED Control Display + Wireless Controllers (left & right) |
| Battery & Charger | Avinox Integrated Battery 800 Wh / Avinox Fast Charger 12A (508 W) |
| Fork | 2026 FOX 36 Factory – 160 mm travel, GRIP X2 Damper, 15×110 mm, 44 mm rake |
| Rear Shock | 2026 FOX FLOAT X Factory – 185×55 mm Trunnion, EVOL Air Sleeve, 2-position lever with LSC adjustment |
| Drivetrain | SRAM X0 Eagle Transmission Derailleur w/ power cable / SRAM AXS Pod Controller / XS-1295 10-52T Cassette / E-MTB 34T Chainring / X0 Eagle Flattop Chain / Avinox SL Crank (M/L 155 mm, XL/XXL 160 mm) |
| Brakes | Magura MT7 Pro hydraulic 4-piston disc brakes, HC levers, 203 mm Storm HC rotors front & rear |
| Wheels | Amflow HMC-30 Carbon 29" rims, 30 mm internal, 28H, tubeless ready / SAPIM E-Light straight-pull spokes / Alloy hubs 15×110 mm & 148×12 mm, 78T |
| Tyres | Front: Maxxis Assegai MaxxTerra 29×2.5" WT 3C EXO E-25 TLR / Rear: Maxxis Dissector MaxxTerra 29×2.4" WT 3C EXO+ E-25 TLR |
| Cockpit | Amflow Enduro Carbon Handlebar (25 mm rise, 800 mm wide, 5° up, 9° back) / Amflow Enduro CNC Stem, 35 mm length, Ø35 mm clamp |
| Seatpost & Saddle | Ergon SM PRO M/L Saddle / FOX Transfer Factory Dropper – travel adjustable in 5 mm steps (M 125–150 mm; L/XL 155–180 mm; XXL 185–210 mm) |
| Accessories | Quick Start Guide, Torque Wrench (3–25 Nm, Hex 2-6 mm, Torx T25), Shock Pump, Front & Rear Lights |
Both models share Amflow’s full-carbon frame, DJI Avinox 105 Nm motor and 800 Wh battery. The Pro adds factory-level suspension, higher-tier SRAM Transmission and carbon wheels.
| Component | PL Carbon (800Wh) | PL Carbon Pro (800Wh) |
|---|---|---|
| Frame | Carbon, Satin Silver, 150 mm, 27.5/29 compatible | Carbon, Cosmic Black, 150 mm, 27.5/29 compatible |
| Motor | Avinox M1, 105 Nm | Avinox M1, 105 Nm |
| Battery | Avinox Integrated 800 Wh | Avinox Integrated 800 Wh |
| Display / Controls | 2" OLED, wireless L/R controllers | 2" OLED, wireless L/R controllers |
| Fork | FOX 36 Performance, 160 mm, GRIP | FOX 36 Factory, 160 mm, GRIP X2 |
| Rear Shock | FOX Float Performance, EVOL, 2-pos | FOX FLOAT X Factory, EVOL, 2-pos + LSC |
| Drivetrain | SRAM Eagle 70 Transmission, XS-1270 10-52T, Single Click | SRAM X0 Eagle Transmission, XS-1295 10-52T, AXS Pod |
| Brakes | Magura MT5, 4-piston, 203 mm MDR-C | Magura MT7 Pro, 4-piston, 203 mm Storm HC |
| Wheels | Amflow HMA-30 Alloy, 32H, 30 mm, tubeless | Amflow HMC-30 Carbon, 28H, 30 mm, tubeless |
| Handlebar | Amflow Enduro Alloy, 35 mm rise, 800 mm | Amflow Enduro Carbon, 25 mm rise, 800 mm |
| Seatpost | KS Rage-i dropper (150-190 mm) | FOX Transfer Factory (adj. in 5 mm steps) |
| Best for | Riders wanting Amflow tech at the best price | Riders wanting no-compromise enduro spec |
| Colours | Cosmic Black |
| Sizes | Large, Medium, X-Large, XX-Large |
| Brand | Amflow |
| Barcodes | 190021116665, 190021116672, 190021116702, 190021116740 |
| SKUs / Part Numbers | CP.EB.00000040.01, CP.EB.00000041.01, CP.EB.00000042.01, CP.EB.00000043.01 |
